Discontinued: Burner Management Systems
Automatic burner control units for continuous operation PFD 778
19'' rack-mounted automatic burner control units for monitoring and control of gas burners, for continuous operation, ionization control, single-electrode operation possible.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
19'' rack-mounted automatic burner control units for monitoring and control of gas burners, for continuous operation, ionization control, single-electrode operation possible. Main gas after safety time or main gas after flame proving period, switchable, restart, immediate fault lock-out or delayed reaction time for V1 following flame failure, switchable.
Features & Benefits:
Features & Benefits:
- Air valve control possible
- Multi-flame control possible
- Safety time on start-up: 3, 5 or 10 s
- Safety time operation for V2: 1 s
- Safety time operation for V1: 1, 3, 5 or 10 s
- Mains voltage: switchable from 220/240 V AC to 110/120 V AC, for grounded or ungrounded mains
- Controlled by standard 24 V DC signals
