gas filtration
Gasket Strainers
Protective gasket strainers for gas applications.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Honeywell Gasket Strainers are an effective way to protect downstream meters and regulators from weld slag and other debris in the gas stream. Available in 2, 3 and 4 ANSI 125/150 size, 20, 40 and 80 mesh, full face or ring gaskets.
Specifications
Connection Options
- Connection Size
- 2 in, 3 in, 4 in
General Overview
- Typical Uses
- Gas systems (removal of debris in gas stream)
- Purpose
- Protect downstream metering and regulation equipment
- Product Type
- In-line gasket strainers
- Mounting Orientation
- Installed between mating flanges or flange and meter/regulator
Construction
- Screen Material
- Stainless Steel
- Mesh Sizes Available
- 20, 40, 80 mesh
- Gasket Material
- GARLOCK 3000 (asbestos-free)
Approvals
- Flange Standard
- ANSI 125/150
Design
- Construction Type
- Wafer construction
Connection Options
- Connection Size
- 2 in, 3 in, 4 in
General Overview
- Typical Uses
- Gas systems (removal of debris in gas stream)
- Purpose
- Protect downstream metering and regulation equipment
- Product Type
- In-line gasket strainers
- Mounting Orientation
- Installed between mating flanges or flange and meter/regulator
Construction
- Screen Material
- Stainless Steel
- Mesh Sizes Available
- 20, 40, 80 mesh
- Gasket Material
- GARLOCK 3000 (asbestos-free)
Approvals
- Flange Standard
- ANSI 125/150
Design
- Construction Type
- Wafer construction
- Connection Size : 2 in, 3 in, 4 in
- Typical Uses : Gas systems (removal of debris in gas stream)
- Screen Material : Stainless Steel
- Purpose : Protect downstream metering and regulation equipment
- Product Type : In-line gasket strainers
- Mounting Orientation : Installed between mating flanges or flange and meter/regulator
- Mesh Sizes Available : 20, 40, 80 mesh
- Gasket Material : GARLOCK 3000 (asbestos-free)
- Flange Standard : ANSI 125/150
- Construction Type : Wafer construction
Data Sheet
Name
Description
File Size
Date
Size
Gasket Strainers Data Sheet (English)
application/pdf 683.06 KB
10/31/2023
683.06 KB
Name
Description
File Size
Date
Size
Gasket Strainers Data Sheet (English)
application/pdf 683.06 KB
10/31/2023
683.06 KB
Name
Description
File Size
Date
Size
Name
Description
File Size
Date
Size
Category@category|Type@type
Filters
Product Number
Please sign in to view part numbers available for purchase based on your account Sign In
Part Number
Description
Leaf Category
Thumbnail
Add to list
94465P007
GASKET STRAINER, 2" 80 MESH
94465P007
GASKET STRAINER, 2" 80 MESH
94465P010
GASKET STRAINER, 2" 20 MESH
94465P010
GASKET STRAINER, 2" 20 MESH
94465P011
GASKET STRAINER, 3" 20 MESH
94465P011
GASKET STRAINER, 3" 20 MESH
94465P012
GASKET STRAINER, 4" 20 MESH
94465P012
GASKET STRAINER, 4" 20 MESH
94465P013
GASKET STRAINER, 2" 20 MESH
94465P013
GASKET STRAINER, 2" 20 MESH
94465P014
GASKET STRAINER, 3" 20 MESH
94465P014
GASKET STRAINER, 3" 20 MESH
94465P015
GASKET STRAINER, 4" 20 MESH
94465P015
GASKET STRAINER, 4" 20 MESH
94465P017
STRAINER-RING FACE 2" 40 MESH ANSI 150
94465P017
STRAINER-RING FACE 2" 40 MESH ANSI 150
94465P018
STRAINER-RING FACE 3" 40 MESH ANSI 150
94465P018
STRAINER-RING FACE 3" 40 MESH ANSI 150
94465P019
STRAINER-RING FACE 4" 40 MESH ANSI 150
94465P019
STRAINER-RING FACE 4" 40 MESH ANSI 150
