WHG Wall Hugger
Flat flame furnace burner with a flat flame profile through the entire firing range.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
WHG Wall Hugger flat flame gas burner is designed for applications requiring even heat distribution with no flame impingement. The burner’s flame pattern promotes even heating by radiation from the furnace walls and roof. The flame hugs the wall allowing the burner to be placed close to the load.
Features & Benefits:
Features & Benefits:
- Direct spark or gas pilot ignition
- Immediate ramping up to high fire reduces furnace heat-up time
- UV or flame rod flame supervision
- Preheated air up to 800ºF (425ºC)
- Stable operation in cold furnace at low excess air
- Even heat distribution with no flame impingement
Specifications
Air & Combustion Air Specifications
- Air Temperature Range
- Preheated air up to 800 deg F (425 deg C)
- Excess Air Limits
- 175 to 400% at 16 osig (6900 Pa) inlet air pressure
- Excess Air Capability
- Can operate with excess air limits of approximately 175 to 400% at high inlet air pressure
Processing & Performance Metrics
- Turndown Capability
- Stable operation from low fire to high fire (model‑dependent)
- Capacity Range
- Approximately 175,000 to 2,300,000 Btu/h (≈ 47 to 610 kW), size‑dependent (Typical)
Product Overview & Classification
- Primary Function
- Even heat distribution with no flame impingement
Control, Logic & System Behavior
- Operation Stability
- Stable in cold furnace at low excess air
- Operating Modes
- On‑ratio firing; operation with excess air
Combustion/Furnace/Chamber Temperatures
- Maximum Chamber Temperature
- Up to 2500 deg F (1370 deg C)
Installation & Mounting Specifications
- Installation Orientation
- Can be installed to fire in any position (roof, sidewall, etc.)
Ignition, Flame & Supervision Specifications
- Ignition Type
- Direct Spark or Gas Pilot Ignition
- Flame Supervision
- UV Scanner or Flame Rod
- Flame Profile
- Flat flame throughout entire firing range
- Flame Geometry
- Short forward flame travel (≈2-6 in/50-150 mm depending on size) (High Fire)
Control, Safety & Timing Characteristics
- Heat-Up Time
- Immediate ramping to high fire
Performance, Flow & Capacity
- Heat Distribution
- Even, with no flame impingement
Combustion, Mixing & Fuel Dynamics
- Combustion Principle
- Flat flame that hugs the furnace wall to promote radiant heating
Overview
- Burner Type
- Wall‑hugging, flat‑flame gas burner
Dimensions & Size Specifications
- Burner Sizes
- WHG 112, 115, 120, 125, 130, 140
Product Design & Configuration
- Burner Family
- WHG Wall Hugger
Air & Combustion Air Specifications
- Air Temperature Range
- Preheated air up to 800 deg F (425 deg C)
- Excess Air Limits
- 175 to 400% at 16 osig (6900 Pa) inlet air pressure
- Excess Air Capability
- Can operate with excess air limits of approximately 175 to 400% at high inlet air pressure
Processing & Performance Metrics
- Turndown Capability
- Stable operation from low fire to high fire (model‑dependent)
- Capacity Range
- Approximately 175,000 to 2,300,000 Btu/h (≈ 47 to 610 kW), size‑dependent (Typical)
Product Overview & Classification
- Primary Function
- Even heat distribution with no flame impingement
Control, Logic & System Behavior
- Operation Stability
- Stable in cold furnace at low excess air
- Operating Modes
- On‑ratio firing; operation with excess air
Combustion/Furnace/Chamber Temperatures
- Maximum Chamber Temperature
- Up to 2500 deg F (1370 deg C)
Installation & Mounting Specifications
- Installation Orientation
- Can be installed to fire in any position (roof, sidewall, etc.)
Ignition, Flame & Supervision Specifications
- Ignition Type
- Direct Spark or Gas Pilot Ignition
- Flame Supervision
- UV Scanner or Flame Rod
- Flame Profile
- Flat flame throughout entire firing range
- Flame Geometry
- Short forward flame travel (≈2-6 in/50-150 mm depending on size) (High Fire)
Control, Safety & Timing Characteristics
- Heat-Up Time
- Immediate ramping to high fire
Performance, Flow & Capacity
- Heat Distribution
- Even, with no flame impingement
Combustion, Mixing & Fuel Dynamics
- Combustion Principle
- Flat flame that hugs the furnace wall to promote radiant heating
Overview
- Burner Type
- Wall‑hugging, flat‑flame gas burner
Dimensions & Size Specifications
- Burner Sizes
- WHG 112, 115, 120, 125, 130, 140
Product Design & Configuration
- Burner Family
- WHG Wall Hugger
- Air Temperature Range : Preheated air up to 800 deg F (425 deg C)
- Turndown Capability : Stable operation from low fire to high fire (model‑dependent)
- Primary Function : Even heat distribution with no flame impingement
- Operation Stability : Stable in cold furnace at low excess air
- Operating Modes : On‑ratio firing; operation with excess air
- Maximum Chamber Temperature : Up to 2500 deg F (1370 deg C)
- Installation Orientation : Can be installed to fire in any position (roof, sidewall, etc.)
- Ignition Type : Direct Spark or Gas Pilot Ignition
- Heat-Up Time : Immediate ramping to high fire
- Heat Distribution : Even, with no flame impingement
- Flame Supervision : UV Scanner or Flame Rod
- Flame Profile : Flat flame throughout entire firing range
- Flame Geometry : Short forward flame travel (≈2-6 in/50-150 mm depending on size) (High Fire)
- Excess Air Limits : 175 to 400% at 16 osig (6900 Pa) inlet air pressure
- Excess Air Capability : Can operate with excess air limits of approximately 175 to 400% at high inlet air pressure
- Combustion Principle : Flat flame that hugs the furnace wall to promote radiant heating
- Capacity Range : Approximately 175,000 to 2,300,000 Btu/h (≈ 47 to 610 kW), size‑dependent (Typical)
- Burner Type : Wall‑hugging, flat‑flame gas burner
- Burner Sizes : WHG 112, 115, 120, 125, 130, 140
- Burner Family : WHG Wall Hugger
Name
Description
File Size
Date
Size
Category@category|Type@type
Filters
Product Number
Please sign in to view part numbers available for purchase based on your account Sign In
Part Number
Description
Leaf Category
Thumbnail
Add to list
101028467
KIT,LIT,WHG,WALL HUGGER GAS BURNERS
101028467
KIT,LIT,WHG,WALL HUGGER GAS BURNERS
HK19663
GSKT,RKG/WHG130 140 FURN MTG LGS STYL 67
HK19663
GSKT,RKG/WHG130 140 FURN MTG LGS STYL 67
HK19687
PLT & TILE ASSY,WHG130 140
HK19687
PLT & TILE ASSY,WHG130 140
HK403043
NZL,WHG130C STSTL GAS INS
HK403043
NZL,WHG130C STSTL GAS INS
HK403044
NZL ASSY,WHG112B STSTL W/PILT IGN
HK403044
NZL ASSY,WHG112B STSTL W/PILT IGN
HK403046
NZL ASSY,WHG115B STSTL W/PILT IGN
HK403046
NZL ASSY,WHG115B STSTL W/PILT IGN
HK404069
NZL ASSY,WHG112 SPRK IGN GAS
HK404069
NZL ASSY,WHG112 SPRK IGN GAS
HK404070
NZL ASSY,WHG115 SPRK IGN GAS
HK404070
NZL ASSY,WHG115 SPRK IGN GAS
HK404070-001
NZL ASSY,WHG115BX GAS OPP AIR
HK404070-001
NZL ASSY,WHG115BX GAS OPP AIR
HK404071
NZL ASSY,WHG120 SPRK IGN GAS
HK404071
NZL ASSY,WHG120 SPRK IGN GAS
