Mounting Brackets
Mounting brackets, designed for the BrightFire 200, to ensure safe and correct installation and removal of the burner into the furnace; an essential item for a good furnace design.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
The burner mounting bracket is an essential component in a well designed combustion system. It assures a safe, reliable burner installation and precise burner alignment. Eclipse offers a complete line of pedestal and gimbal arm type mounting brackets specifically designed for use with our glass industry burner products. Our brackets provide precise, repeatable adjustment and allow for easy burner installation and removal. The robust construction delivers reliability and long operational life.
Specifications
Actuation, Control & Motion Characteristics
- Adjustment Principle
- Gimbal pivot point (sealed angular adjustment)
Mechanical Design & Hardware Details
- Vertical Adjustment
- ± 1 in
- Bracket Style
- Arm Style/Pedestal Style
Installation & Mounting Specifications
- Mounting Orientation
- Side‑of‑port (arm style)/Under‑port (pedestal style) millimetre
Applications & Compatibility
- Compatible Equipment
- Burners with ball‑end tip and socket plate
- Applications
- Burner mounting and alignment
Actuation, Valve & Motion Control Specifications
- Axial Rotation Capability
- 360 deg
Mechanical Design & Adjustment Characteristics
- Angular Adjustment
- Horizontal/Vertical - ± 7 deg
Actuation, Control & Motion Characteristics
- Adjustment Principle
- Gimbal pivot point (sealed angular adjustment)
Mechanical Design & Hardware Details
- Vertical Adjustment
- ± 1 in
- Bracket Style
- Arm Style/Pedestal Style
Installation & Mounting Specifications
- Mounting Orientation
- Side‑of‑port (arm style)/Under‑port (pedestal style) millimetre
Applications & Compatibility
- Compatible Equipment
- Burners with ball‑end tip and socket plate
- Applications
- Burner mounting and alignment
Actuation, Valve & Motion Control Specifications
- Axial Rotation Capability
- 360 deg
Mechanical Design & Adjustment Characteristics
- Angular Adjustment
- Horizontal/Vertical - ± 7 deg
- Adjustment Principle : Gimbal pivot point (sealed angular adjustment)
- Vertical Adjustment : ± 1 in
- Mounting Orientation : Side‑of‑port (arm style)/Under‑port (pedestal style) millimetre
- Compatible Equipment : Burners with ball‑end tip and socket plate
- Bracket Style : Arm Style/Pedestal Style
- Axial Rotation Capability : 360 deg
- Applications : Burner mounting and alignment
- Angular Adjustment : Horizontal/Vertical - ± 7 deg
Manuals and Guides
Name
Description
File Size
Date
Size
Name
Description
File Size
Date
Size
Name
Description
File Size
Date
Size
Name
Description
File Size
Date
Size
Category@category|Type@type
Filters
Product Number
Please sign in to view part numbers available for purchase based on your account Sign In
Part Number
Description
Leaf Category
Thumbnail
Add to list
013415
BLCK,PLT,SOC,M SZ,CS
013415
BLCK,PLT,SOC,M SZ,CS
014575
BLCK,HOLD DOWN,SOC PLT,GBL,G SZ
014575
BLCK,HOLD DOWN,SOC PLT,GBL,G SZ
016054
BRKT,BUCKSTAY PLT & CHNL SUPP ASY,UNISEX
016054
BRKT,BUCKSTAY PLT & CHNL SUPP ASY,UNISEX
016113
T BOLT,LOCK,BRNR,PEDESTAL GBL BRKT
016113
T BOLT,LOCK,BRNR,PEDESTAL GBL BRKT
016204
SCR,ADJ,5.125 IN. LG,VERT ANG. REF.09611
016204
SCR,ADJ,5.125 IN. LG,VERT ANG. REF.09611
018064
HLDR,CAP SCR,ASSY,GBL BRKT
018064
HLDR,CAP SCR,ASSY,GBL BRKT
018134
UPR BDY SLV CSTG UNISEX ARM GBL BRKT, WA
018134
UPR BDY SLV CSTG UNISEX ARM GBL BRKT, WA
018397
CYL,RODLESS,CCTV,ASSY,W NEW END CAPS AND
018397
CYL,RODLESS,CCTV,ASSY,W NEW END CAPS AND
018416-001
HOSE,FLX,ASSY,1/2 IN.,AIR,120 IN. LG,BRD
018416-001
HOSE,FLX,ASSY,1/2 IN.,AIR,120 IN. LG,BRD
018416-002
HOSE,FLX,ASSY,3/8 IN.,AIR,120 IN. LG,BRD
018416-002
HOSE,FLX,ASSY,3/8 IN.,AIR,120 IN. LG,BRD
